SFF Coaxial Cable

Short Description:

Product Model: SFF Coaxial Cable

Execution standard:

Product features:

1) Rated voltage:

2) Temperature resistance: -65℃~150℃

3) Conductor: silver-coated wire/silver-coated copper wire

4) Insulation: PTFE

5) Shielding: silver plating shielding

6) Sheath: FEP

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Features/uses:

Excellent corrosion resistance, oil resistance strong acid resistance strong alkali strong oxidant, etc. It has excellent electrical insulation performance, high voltage and high frequency loss, no moisture absorption and high insulation resistance; It has excellent fire resistance, aging resistance, high temperature resistance, attenuation resistance, stable transmission and long service life

Model	Inner conductor mm	Conductor material	Insulation mm	Insulation material	Shield material	Jacket material	Jacket mm	Resistance Ω	Rate	Attenuation dB/m
Model	Inner conductor mm	Conductor material	Insulation mm	Insulation material	Shield material	Jacket material	Jacket mm	Resistance Ω	Rate	400	3000
SFF-50-1	7/0.10	Silver plated copper	0.87	PTFE	Silver plated copper	FEP	1.8	50	70%	1.05	2.91
SFF-50-1.5-1	7/0.18		1.5				2.55	50		0.58	1.65
SFF-50-1.5-2	7/0.18		1.5				3.2	50		0.58	1.65
SFF-50-2-1	1/0.73		2.2				3.3	50		0.42	1.27
SFF-50-2-2	1/0.73		2.2				4	50		0.42	1.27
SFF-50-3-1	1/0.93		3				4.5	50		0.27	0.82
SFF-50-3-2	1/0.93		3				5.5	50		0.27	0.82
SFF-50-5	1/1.48		4.6				6.4	50		0.22	0.67
SFF-75-1	1/0.17		0.87				1.8	75		0.93	2.61
SFF-75-1.5-1	7/0.10		1.5				2.55	75		0.57	1.60
SFF-75-1.5-2	7/0.10		1.5				3.2	75		0.57	1.60
SFF-75-2-1	1/0.4		2.2				3.2	75		0.40	1.21
SFF-75-3-1	1/0.55		3				4.5	75		0.29	0.84
SFF-75-3-2	1/0.55		3				5.5	75		0.29	0.84
SFF-75-5	1/0.82		4.6				6.4	75		0.19	0.66
